Injection mold compound
본문
-
Application
- Rubber boots, various molding products
Features
- Free of RoHS (Pb, Cr6+, Cd, Hg, PBBs, and PBDEs) restricted heavy metal.
- Excellent workability and transparency
-
Major physical properties and process temperature
| Test Item | UNIT | Value | Test method | ||
|---|---|---|---|---|---|
| WS-101MBGS(45%) | S-24 | ||||
| Room Temp. | Tensile Strength | Mpa | 15.6 | 15.6 | ASTM D 638 |
| Elongation | % | 346 | 308 | ||
| Aging Test (100℃×48) |
Retention of T/S | % | 88 | 91 | ASTM D 638 |
| Retention of E/L | % | 90 | 92 | ||
| Thermal Stability (200℃) |
hrs | 3:35 | 5:15 | JIS K 6723 | |
| Specific Gravity | - | 1.23 | 1.40 | ASTM D 792 | |
| Hardness | Shore A | 58 | ASTM D 2240 | ||
| RoHS (Pb, Cr6+, Cd, Hg, PBBs, PBDEs) |
PPM | N.D. | N.D. | XRF | |
| Application | For boots | Plug Moulding | |||
- Product characteristics shown above are only guidelines not the actual product specification.
- Process temperature conditions for the product may differ according to the technical spec of the machinery and processing condition.
