Irradiation crosslinking PE compound (for hybrid automobile wire)
본문
-
Application
- Insulator for high heat resistant automobile wire used for starting engine and charging battery. Irradiation crosslinking PE compound.
-
Features
- Outstanding crosslinking
- Excellent property and workability
- Free of RoHS (Pb, Cr6+, Cd, Hg, PBBs, and PBDEs) restricted heavy metal.
Major physical properties and process temperature
| Test Item | UNIT | Value | Test method | |
|---|---|---|---|---|
| AEX | ||||
| Room Temp. | Tensile Strength | Mpa | 11 | ASTM D 638 |
| Elongation | % | 611 | ||
| Aging Test 1 | 1KV | - | PASS (150℃× 240hr) |
ISO 6722 |
| Aging Test 2 | 1KV | - | PASS (200℃×30min) |
JASO D 618 |
| Oil Test | 1KV | - | PASS | JASO D 618 |
| Low Temp
Resistance (-40℃) |
IKV | - | PASS | KSC 3004 |
| Specific Gravity | - | 1.31 | ASTM D 792 | |
| Hardness | Shore A | 92 | ||
| Description | E-beam Cure | |||
| Application | AEX, AEXXF | |||
- Product characteristics shown above are only guidelines not the actual product specification.
- Process temperature conditions for the product may differ according to the technical spec of the machinery and processing condition.
PE COMPOUND
| Grade | Workable Temperature | HYUNDAI | KIA | GM | Renault samsung | NISSAN | FORD |
|---|---|---|---|---|---|---|---|
| T3 | 125℃ | WS-7125FR, AEX | |||||
| T4 | 150℃ | WS-7150FR | |||||
